Type 4040 AM/RL
Design AM/RL
For connecting to drawbar eyes.
DIN 74054 · ISO 8755
| Technical data | |||
| Coupling | Flange size | Order nr. | ECE type approval |
| 4040/G135 AM/RL | 120 x 55 mm | 14 999 513 | E11 55R-016290 |
| 4040/G145 AM/RL | 140 x 80 mm | 14 999 521 | E11 55R-016291 |
| 4040/G150 AM/RL | 160 x 100 mm | 14 999 529 | E11 55R-016292 |
| Performance data | ||||
| Coupling | D kN |
Dc kN |
V kN |
Admiss. supporting load kg |
| 4040/G135 AM/RL | 85 | 70 | 28,2/25 | 700/1000 |
| 4040/G145 AM/RL | 100 | 92 | 38 | 1000 |
| 4040/G150 AM/RL | 137 | 92 | 40 | 1000 |
