VBG Endplate kit EDF 300 375x600, 21-574778
The EDF 300 endplate kit is intended for fully underslung drawbeam installation.Intended for holes bored within the reference dimensions.EDF 300 is available in different widths and length.
| Weight | 35.4 kg |
|---|---|
| Size | M14/M16 |
| Vehicle manufacturer | Universal |
| Hole pattern chassi | Undrilled mm |
| Screw consumption (pcs) | Min 24 |
| Mounting height | Low |
| Coupling height End plate (mm) | 300-380 |
| Installation | Underslung mounted |
| Dimension (w x h) | 375 x 600 |
| VBG Endplate EDF 300 - 21-574778 - Information drawing.dxf | Information Drawing |
|---|---|
| VBG End plate EDF 300 - Mounting instruction - 38-300200.pdf | Mounting Instruction |
